Small ABS 60 Amp Junction Box Clear Plastic Electronic Enclosures Carton Package

Product Categories
Zhejiang Guokong Electric Co., Ltd.
Contact Now

Small ABS 60 Amp Junction Box Clear Plastic Electronic Enclosures Carton Package

  • 1
  • 2

Place of Origin : China

Brand Name : QK

Certification : RoHS, CE, UL,CCC,ISO9001

MOQ : 1 Piece

Payment Terms : T/T,L/C,Western Union

Price : Negotiation

Packaging Details : Regular export packing and can accept customized

Supply Ability : 1000 Pieces/month

Delivery Time : 5-8 work days

Model Number : GK110808

Color : Grey

Product Name : Plastic junction box

OEM : Offered

External Size : 110*80*85mm

Material : ABS Plastic

Package : Carton

Contact Now

Waterproof Breaker Box ABS Junction Box Grey Color Dimension

Product Description
1. ABS or ABS+PC material;
2. The enclosure include Cover,Base,Sealing and Screw;
3. Operating temperature:-20°C to 85°C;
4. Protection Class: IP65;
5. Color: Light grey or accord your requirement;
6. Most of products can be modifications, such as drilling holes, adding and changing PCB pillars;
7. Indoor and outdoor installations,rapid Deployment Installations,corrosive environments & hotspot applications;

Installation:

1. Inside: There are the installation holes in the base for circuit board or din rail.
2. Outside: The products can be directly fixed on the wall or other flat boards with

screws or nails via the screw holes in the base.

Outlet hole: Holes can be opened on the box as customers' requirements, and installing cable gland can bring with better waterproof performance.

1. Appearance

One Piece polyurethance sealing ring making better watertighe,dustproof per-formance and long lasting use cycle.

2. Plastic Screw

Anit fall design,farewell aerial work screws easily lost.

3. Mounting Screws

With mounting screws and holes,the installation is quick and conventient.

4. High Quality Material

Using ABS raw materials,having the function of waterproofing,corrosion resistancing,anti-aging.

Standard (Grey) H*W*D Weight (KG/piece) Piece/Carton Carton Size (CM) Net Weight (KG/carton)
GK090605 95*65*55 0.12 160 410*340*450 18.4
GK110807 110*80*70 0.16 90 410*340*450 15.1
GK110808 110*80*85 0.19 75 410*340*450 14.5
GK130807 130*80*70 0.18 140 520*420*530 26.4
GK130808 130*80*85 0.21 120 520*420*530 25.7
GK101007 100*100*75 0.17 140 520*420*530 25.4
GK101009 100*100*90 0.21 112 730*410*410 23.7
GK180807 180*80*70 0.24 100 730*410*410 24.4
GK250807 250*80*70 0.33 70 520*420*530 21.3
GK250808 250*80*85 0.34 60 520*420*530 20.9
GK121207 125*125*75 0.24 72 510*380*470 18.2
GK121209 125*125*90 0.28 60 510*380*470 17.5
GK171207 175*125*75 0.32 60 730*410*410 19.7
GK171210 175*125*100 0.38 48 730*410*410 19.1
GK171409 170*140*95 0.39 45 520*420*530 18.5
GK171710 175*175*100 0.48 36 520*420*530 18
GK201510 200*150*100 0.44 40 620*410*510 19.6
GK202009 200*200*95 0.59 30 620*410*510 18.6
GK251510 250*150*100 0.57 32 620*410*510 19
GK281913 280*190*130 0.93 16 570*390*550 16.1

Small ABS 60 Amp Junction Box Clear Plastic Electronic Enclosures Carton Package
